| Max. pad printing plate size(mm) |
100x250 |
| Max pad printing printing diameter(mm) |
Ø82 |
| Max pad printing length(mm) |
82 |
| Max pad head downward travel(mm) |
50 |
| Max pad head forward travel(mm) |
125 |
| Work table X-axis travel(mm) |
35 |
| Pad printers work table Y-axis travel(mm) |
35 |
| Pad printers work table Z-axis travel(mm) |
130 |
| Pad printers work table offset angle(°) |
18 |
| Pad adjustment X-axis(mm) |
45 |
| Pad adjustment Y-axis(mm) |
40 |
| Shuttle stroke(mm) |
|
| Conveyor pitch of index(mm) |
|
| No of jig fixture(pc) |
1 |
| Distance between work pieces(mm) |
|
| Max work piece height(mm) |
130 |
| Pad printing pressure(MPa) |
11.8 |
| Max pad head forward pressure(MPa) |
4.8 |
| Shuttle pressure(MPa) |
|
| Conveyor pressure (MPa) |
|
| Max pad printing speed(pcs/min) |
20 |
| Air pressure(MPa/cm2) |
0.45-0.60 |
| Air consumption(L/min) |
8 |
| Power supply |
110/220V 50/60Hz |
| Power consumption(W) |
10 |
| Machine dimension(mm) |
780X400X1310 |
| Packing dimension(mm) |
960X580X1550 |
| Net weight(kg) |
120 |
| Gross weight(kg) |
158 |
