1~3 color screen printing and film covering machine,Large flat sheet screen printing & film laminating equipment,Automatic screen printing film covering machine
|
| PM-S2000A3CC |
| |
| |
Features: |
| |
- Professionally design and manufacture 1~3 color screen printing and film covering machine, Large flat sheet screen printing & film laminating equipment, Automatic multi color screen printing and film covering production line.
- This 1~3 color screen printing and film covering machine, Large flat sheet screen printing & film laminating equipment, Automatic screen printing film covering machine is designed and tailored to the 1~3 color silk screen printing on small and large flat sheet substrate products such as metal plates, doors, advertising boards, glass sheets and similar products etc.
- The whole system is consist of a loading machine, 3 stations of 4-lifting-post flat vacuum screen printing machines, 3 stations of UV curing machines, film covering machine and unloading coveyor etc.
- Reasonable structure, accurate and stable on multi color screen printing and film covering performance.
- Integrates with variable frequency motor, servo motor, PLC and touch screen etc for good and easy operation control.
- With 0~30mm big space printing height adjustment..
- Equips with automatic screen peeling facility, the screen printing structure of 4 posts synchronous lifting system can achieve better printing results.
- Squeegee and ink scraper can be set to stop before or after printing.
- With three operating modes: Automatic, Semi Automatic and Manual
|
| |
Main Specifications: |
| |
| Max screen printing area |
1800x1000mm |
| Screen printing table size |
2000x1500mm |
| Max screen frame size |
2400x1700mm |
| Printing substrate thickness |
<=30mm |
| Max screen printing speed |
>=40 Pcs/Hr |
| Power supply |
3 phase 380V |
| Air supply |
0.6~0.75Mpa/cm2 |
| Machine dimension |
31000x2800x2800mm |
| Machine weight |
4980kg |
|
| |
|
|
