Flat Round Oval Screen Printer,Pneumatic Multi Function Silk Screen printing Machine,Semi Automatic Plane Cylindrical Oval Conic Screen Printing Equipment

PM-S400M

Features:

Professionally Manufacture Wholesale Flat Round Oval Screen Printer, Pneumatic Multi Function Silk Screen printing Machine, Semi Automatic Plane Cylindrical Oval Conic Screen Printing Equipment.
The Flat Round Oval Screen Printer, Pneumatic Multi Function Silk Screen printing Machine, Semi Automatic Plane Cylindrical Oval Conic Screen Printing Equipment is suitable for printing on flat, round and oval items including conical, cylindrical or any round surfaces with various materials such as paper, wood, plastic, metal, glass, or ceramic etc.
Applies the German and Japanese pneumatic control elements for quiet and accurate printing.
Different work sets (See download) are attached with the machine for different printing purposes.
The printing table has vacuum function to secure fixing of substrate throughout the entire cycle or intermittently.
Can be operated in manual, semi-auto, or fully automatic mode to suit different worker's skill level.
Squeegee/flood bar depth, pressure, speed, leveling, and stroke etc. are all adjustable to fit your various printing needs.
Work table and screen frame are easy to install and dismount.

Main Specifications:

Model No.	PM-S400M
Max. printing area (for round items)	∮150x200mm(L)
Max. printing area (for flat items)	250x350mm
Size of printing table	300x400mm
Max. frame size	400x630mm
Max. printing speed	13 pcs/min
Power	220v 410W
Air pressure	0.5-0.65 Mpa/cm2
Air consumption	6 L/min
Air compressor	3hp
Machine dimension	780x830x1500mm
Packing measurement	960x1010x1740mm
Net weight	246kg
Gross weight	327kg

Standard Accessories:

Plane set	1 set
Wheeling set	1 set
Blowing/Spring set	1 set
Different sizes squeegees and flood bars	6 sets
Adjustment tools	1 set
